| Operating power supply | Three-phase five-wire 220V 60Hz |
| Operating conditions | Ambient temperature: -10℃ to +40℃; Relative humidity: <85% (at 25℃) |
| Dimension | Frame dimensions: 1320mm*540mm*860mm; Hydraulic station dimensions: 550mm*430mm*480mm |
| Weight | ≤400kg |
| No. | Name | Qty |
| 1 | Main power module | 1 |
| 2 | 24V power module | 1 |
| 3 | Button module (with indicator light) | 1 |
| 4 | Relay module | 1 |
| 5 | Emergency stop module | 1 |
| 6 | PLC unit | 1 |
| 7 | Equipment hydraulic components | 1 |
| 8 | Hydraulic station | 1 |
| No. | Name | Qty |
| 1 | Hydraulic hose 1.5m | 2 |
| 2 | Hydraulic hose 1m | 6 |
| 3 | Hydraulic hose 0.6m | 10 |
| 4 | 0.5m 2mm safety electrical cable | 15 |
| 5 | Network cable 1.5m | 1 |
| 6 | 2mm safety electrical cable 100cm black | 5 |
| 7 | 4mm safety electrical cable cable yellow | 1 |
| 8 | 2mm safety electrical cable 100cm yellow | 5 |
| 9 | 4mm safety electrical cable yellow-green | 1 |
| 10 | 4mm safety electrical cable blue | 1 |
| 11 | 2mm safety electrical cable 100cm green | 5 |
| 12 | 2mm safety electrical cable 100cm red | 5 |
| 13 | Speed control valve | 4 |
| 14 | Five-way valve | 4 |
| 15 | Three-way valve | 3 |
| 16 | Throttle valve | 1 |
| 17 | Hydraulic ball valve | 1 |
